Portallayout

Employment/Purpose

A portallayout lays out a container which can have multiple columns, and each column might have any number panels placed vertically with different heights. Portallayout allows users to drag-and-drop a panel to change its location.

When using Portallayout, you have to assign the width (either percentage or pixel) to each Portalchildren, or the result might depend on the browser, and not as expected.

Example

ZKComRef Portallayout Example.PNG


<portallayout>
	<portalchildren width="50%">
		<panel height="150px" title="Yahoo">
			<panelchildren>
				<iframe width="100%" src="http://www.yahoo.com/"/>
			</panelchildren>
		</panel>
		<panel height="300px" title="Google">
			<panelchildren>
				<iframe width="100%" src="http://www.google.com/"/>
			</panelchildren>
		</panel>
	</portalchildren>
	<portalchildren width="50%">
		<panel height="150px" title="ZK">
			<panelchildren>
				<iframe width="100%" src="http://www.zkoss.org/"/>
			</panelchildren>
		</panel>
	</portalchildren>
</portallayout>

Row based layout

[Since ZK 7.0.0]

If you want the portallayout displayed as row based layout, you can specify the orient property to horizontal.

Default is vertical.

For example,

<portallayout orient="horizontal">
	<portalchildren width="50%">
		<panel height="150px" title="Yahoo">
			<panelchildren>
				<iframe width="100%" src="http://www.yahoo.com/"/>
			</panelchildren>
		</panel>
		<panel height="300px" title="Google">
			<panelchildren>
				<iframe width="100%" src="http://www.google.com/"/>
			</panelchildren>
		</panel>
	</portalchildren>
	<portalchildren width="50%">
		<panel height="150px" title="ZK">
			<panelchildren>
				<iframe width="100%" src="http://www.zkoss.org/"/>
			</panelchildren>
		</panel>
	</portalchildren>
</portallayout>

Supported Events

Name
Event Type
onPortalMove
Event: PortalMoveEvent

Represents an event caused by a portal being moved.

Supported Children

* Portalchildren

Use Cases

Version Description Example Location


Version History

Last Update : 2013/10/30


Version Date Content
7.0.0 October, 2013 Portallayout supports row based orientation
